Specifications:
- Brand Name:- Brocade
- Part Number:- 57-1000495-01
- Product Category:- Transceivers
- Transceiver Type:- SFP+
Dimensions:
- Product Dimensions(LxWxH):- 7.11 x1.35×0.85 Cm/ 71.1 x 13.5 x 8.55 mm
- Weight: 0.11 kg/ 0.24 Lbs
- Product Shipping Dimensions(LxWxH): 4″x4″x2″
Brief Details:
- Data Speed:- FC 16G 32G 64G
- Center Wavelength:- 850nm
- Fiber Type:- Multimode
- Transmission:- @64GFC 70M OM3, 100M OM4
- Connector:- Dual LC
- Lasers: VSCEL:- + PIN
- Tx power:- -7.5 to 4 dBm
- Rx sensitivity:- -9.4 to 4 dBm max
- Extinction Ratio:- 3 dB
- Power Consumption:- 3.2 W
- Single Power Supply:- 3.3 V
We kept stock in New, Used, and Refurbished condition.
The Brocade 57-1000495-01 64Gb Fibre Channel (FC) SFP+ Optical Transceiver is designed for high speed in data center applications. This transceiver has a data rate of up to 64 Gbps to ensure that data transfer in some of the most sensitive applications is fast and effective. Equipped with dual LC connectors it seamlessly integrates with several Brocade switches namely, Brocade G720, Brocade G620, and Brocade X6 Director. Its shortwave optical design is a Wavelength of 850 nm optimized for MMF connections; it can reach 70 meters with OM3 fiber and up to 100 meters with OM4 fiber.
The Brocade 57-1000495-01 64Gb Fibre Channel (FC) SFP+ Optical Transceiver integrates easily with the Brocade G720, G620, X6 Director, and DCX 8510 series and other Brocade switches and directors and the Brocade 7810 Extension Switch. This transceiver has a low power consumption of only 3.2 watts, which translates to low costs in power consumption while at the same time being highly efficient. Versatile with a specific laser type – VSCEL has allowed the achievement of stable signal transmission power levels ranging from -7.5 to 4 dBm or the receiver sensitivity up to -9.4 dBm; the result is highly effective and rather robust data flow.
FAQs
What is the maximum end speed of the system unit part number Brocade 57-1000495-01?
It supports up to 64 Gbps for data rate to enhance data transfer.
Which fibers of this meeting are appropriate with this transceiver?
This is for multimode fiber, compatible with OM3 and OM4 connections.
Which Brocade switches are supported for this transceiver?
This transceiver works with the Brocade G720, G620, and X6 Director switches.
