Specifications:
- Brand Name:- Juniper
- Part Number:- JNP-25G-AOC-2M
- Product Category: Cables
- Connector:- SFP28 to SFP28
- Max Data Rate:- 25Gbps
- Cable Length:- 2 meters/6.6 feet
- Fiber Cable:- OM3 MMF
- Minimum Bend Radius:- 7.5mm
- Operation Temperature:- 0~ 70 °C (32 to 158°F)
- Protocols:- 25 Gigabit Ethernet
- Weight: 0.16 kg/ 0.36 Lbs
- Dimension (LxWxH):- 12 x 9 x 2 inches
- If you need Juniper JNP-25G-AOC-10M, We have
JNP-25G-AOC-2M
The Juniper Networks JNP-25G-AOC-2M is an exclusive active optical cable that supports 2 meters of 25 Gigabit Ethernet. This cable has SFP28 connectors installed on each end. It can be permanently used, avoiding any need for connection and disconnection with other devices, and allows fast data transfer within shorter distances.
It is based upon and is compliant with IEEE Std 802.3by-2016 and SFF-8402 standards and supports digital optical monitoring, which in turn provides the ability to monitor laser bias current, RX input power, case temperature, and power supply voltage. As for the cable, it works at 25.78125 GBd per lane and, uses only 1.5 watts of power and is, therefore, both small and dependable.
Designed for operational commercial applications, the JNP-25G-AOC-2M integrated successfully operates at temperatures of 0°C to 70°C and can be stored at -40°C. Weighing only 0.15 kg this is due to its great design and it is light in weight a factor that makes it possible for it to easily install in the network.
The JNP-25G-AOC-2M cable is a 25G AOC cable that has been specially created to interconnect Juniper Networks switches with SFP28 ports that are with 25G at short connector lengths of up to 2 meters. It is normally used with switches referred to as the QFX5120, QFX5200, and the EX4600 among others. This cable offers fast and dependable links for data centers as well as enterprise networks.
FAQs
What is the power consumption of AOC vs DAC?
AOC uses more power than DAC, approximately 2-3 watts, and on the other hand, DAC uses less than 1 watts.
What are the advantages of AOC?
AOC has higher bandwidth, longer reach and better signal quality, it is suitable for high speed networks
What is the maximum voltage of AOC and the purpose of an AOC?
The maximum voltage is 3.3V. As for the purpose of AOC it is utilized for transmitting high-speed data with low signal attenuation over large distances.
