Specifications:
- Brand Name:- Juniper
- Part Number:- EX-SFP-1GE-LX40K
- Product Category:- Transceivers
- Transceiver Type:- SFP
- Media Type:- Single-Mode Fiber (SMF)
Parameters:
- TX Wavelength:- 1310 nm.
- RX Wavelength:- 1310 nm.
- Minimum Optical Budget:- 17 dB
- Maximum Distance:- 40km
- Supported Data Rate:- 1.063-1.25Gbps
- Supported Applications:- Gigabit Ethernet (1.25 Gbps), 1G Fiber Channel (1.0625 Gbps)
- Temperature Range:- Standard 0°-70°C
Brief Details:
- DDM/DOM:- Support
- Connectors:- Double LC
- Tx Wavelength Bandwidth:- 100 nm (1260-1360 nm)
- Rx Wavelength Bandwidth:- 100 nm (1260-1360 nm)
- Minimum Transmitting Power:- -6 dB
- Maximum Transmitting Power:- 0 dB
- Receiver Sensitivity:- -23 dBm
- Receiver Overload:- -3 dBm
- Dispersion:- 300-400 ps/nm
- Transmitter Type:- DFB Laser
- Receiver Type:- PIN photodiode
- Power:- +3.3V single power supply
- Chipset:- MAXIM, MINDSPEED, SEMTECH
Dimensions:
- Production Dimensions (LxWxH):- 7.24 x 1.84 x 1.35 Cm/ 72.4 x 18.4 x 13.5 mm
- Weight: 0.1 kg/ 0.22 Lbs
- Product Shipping Dimensions(LxWxH): 4″x4″x2″
- If you need a Juniper QDD-4X100G-FR, We Have
We kept stock in New, Used, and Refurbished condition.
