Specifications:
- Brand Name:- Juniper
- Part Number:- JNP-QSFP-40GE-IR4
- Product Category:- Transceivers
- Transceiver Type:- QSFP+
- Max Data Rate:- 41.2Gbps (4x 10.3Gbps)
Parameters:
- Wavelength:- 1310nm
- Max Cable Distance:- 2km
- Commercial Temperature Range:- 0 to 70°C (32 to 158°F)
- Receiver Overload:- 2.3dBm
- Power Consumption:- ≤3.5W
- Extinction Ratio:- >3.5dB
Brief Details:
- Connector:- Duplex LC
- Media:- SMF
- Transimitter Type:- DFB CWDM
- Receiver Type:- PIN
- TX Power:- -7~2.3dBm
- Receiver Sensitivity:- <-11.5dBm
- Power budget:- 4.5dB
- Host FEC:- Supported
- Bit Error Ratio (BER):- 1E-12
- Protocols:- 40G Ethernet, Fibre Channel, SATA/SAS3, MSA Compliant
Dimensions:
- Production Dimensions (LxWxH):- 7.24 x 1.84 x 1.35 Cm/ 72.4 x 18.4 x 13.5 mm
- Weight: 0.1 kg/ 0.22 Lbs
- Product Shipping Dimensions(LxWxH): 4″x4″x2″
- If you need a Juniper JNP-QSFP-40G-LR4, We Have
We kept stock in New, Used, and Refurbished condition.
