Juniper Original QDD-400G-FR4 740-085349 2km 1310nm Transceivers Module

Specifications:

• Brand Name:- Juniper
• Part Number:- QDD-400G-FR4
• Product Category:- Transceivers
• Transceiver Type:- QSFP-DD

Parameters:

• Max Data Rate:- 400Gbps
• Wavelength:- 1271nm,1291nm,1311nm,1331nm
• Max Cable Distance:- 2km
• Connector:- Duplex LC (UPC)
• Temperature Range:- 0 to 70°C (32 to 158°F)

Brief Details:

• Media:- SMF
• Transmitter Type:- CWDM EML
• Receiver Type:- PIN
• TX Power:- -3.3~3.5dBm
• RX Power:- -7.3~3.5dBm
• Power budget:- 4dB
• Modulation:- 8x 50G PAM4
• Power Consumption:- ≤ 9W
• Extinction Ratio:- 3.5dB
• DDM/DOM:- Supported
• DSP:- TX and RX
• Inbuilt FEC:- No
• Core Size:- G.652/9um

Dimensions:

• Product Dimensions(LxWxH):- 9.33 x1.8×1.35 Cm/ 93.26 x 18.35 x 13.5 mm
• Weight:- 0.2 Kg/ 0.44 Lbs
• Product Shipping Dimensions(LxWxH): 4″x4″x2″
• If you need a Juniper QDD-4X100G-FR, We Have

We kept stock in New, Used, and Refurbished condition.
